Build your solar system with the right cable. This PV1-F Solar Cable uses a copper conductor with XLPO insulation and is designed for solar installations where resistance to UV, water, abrasion and outdoor weather conditions matters.
| Detail | Information |
|---|---|
| What is it? | A photovoltaic solar cable for connecting solar panels and related PV equipment |
| Who is it for? | Solar installers, electricians, contractors, businesses and homeowners |
| What problem does it solve? | Provides suitable electrical cabling for solar PV installations |
| Why is it better? | Copper conductor with XLPO insulation and resistance to UV, water, abrasion and weathering |
| Voltage Rating | Up to 1500V DC as specified |
| Cable Type | PV1-F Photovoltaic Solar Cable |
| Available Sizes | 1.5mm², 2.5mm², 4mm², 6mm², 10mm² |
Guaranteed safe & secure checkout
| Feature | Benefit |
| Copper Conductor | Provides good electrical conductivity |
| PV1-F Solar Cable | Designed specifically for photovoltaic solar applications |
| XLPO Insulation | Provides insulation suitable for demanding solar installations |
| Up to 1500V DC | Suitable for appropriately designed high-voltage PV systems |
| UV Resistant | Helps the cable withstand exposure to sunlight |
| Water Resistant | Helps protect against moisture in outdoor installations |
| Abrasion Resistant | Provides better resistance against physical wear |
| Ozone Resistant | Designed to withstand ozone exposure |
| Weather Resistant | Suitable for outdoor solar environments |
| Multiple Cable Sizes | Choose a suitable cross-section based on your solar system design |
| Black & Red Options | Makes positive and negative cable identification easier |
| Ghana Situation | How This Cable Helps |
| Strong sunlight | UV-resistant insulation helps the cable handle outdoor exposure |
| Outdoor rooftop installations | Designed for photovoltaic applications and outdoor use |
| Rainy seasons | Water-resistant construction provides added protection against moisture |
| Hot weather | XLPO insulation is designed for demanding solar environments |
| Growing solar installations | Provides suitable cabling for residential and commercial PV systems |
| Solar farms & larger projects | Available in several cross-sections for different system requirements |
| Need for reliable wiring | Copper conductor provides good electrical conductivity |
| Specification | Details |
| Brand Name | DIECAI |
| Model Number | PV1-F |
| Product Type | Photovoltaic Solar Cable |
| Conductor Material | Copper |
| Conductor Type | Photovoltaic Conductor |
| Insulation Material | XLPO |
| Rated Voltage | Up to 1500V DC as specified |
| Available Cross Sections | 1.5mm², 2.5mm², 4mm², 6mm², 10mm² |
| Available Colours | Black / Red |
| UV Resistance | Yes |
| Water Resistance | Yes |
| Abrasion Resistance | Yes |
| Ozone Resistance | Yes |
| Fluid Resistance | Yes |
| General Weathering Resistance | Yes |
| Certification | TUV / CE / ISO |
| IP Level | IP54 |
| Origin | Guangxi, China |
| Application | Suitable? |
| Solar Panel Wiring | ✅ |
| Residential Solar Systems | ✅ |
| Commercial Solar Systems | ✅ |
| Rooftop Solar Installations | ✅ |
| Off-Grid Solar Systems | ✅ |
| Hybrid Solar Systems | ✅ |
| Solar Farms | ✅ |
| Solar Water Pump Systems | ✅ |
| Solar Battery Systems | ✅ |
| Solar Installation Projects | ✅ |
| Size | Typical Use* |
| 1.5mm² | Smaller PV wiring applications |
| 2.5mm² | Smaller solar installations and suitable PV connections |
| 4mm² | Common solar PV wiring applications |
| 6mm² | Higher-current PV connections |
| 10mm² | Larger-current applications and longer cable runs where correctly sized |
The correct cable size depends on current, cable length, voltage drop, installation method, temperature and system design. Do not select cable size based on panel wattage alone.
| Step | What To Do |
| 1. Determine cable size | Select the correct cross-section based on the system's current and installation requirements |
| 2. Identify polarity | Use the red and black cables appropriately for positive and negative connections |
| 3. Measure the run | Allow enough cable for the actual distance between components |
| 4. Make proper connections | Use compatible PV connectors and correctly rated terminals |
| 5. Secure the cable | Keep cables properly supported and protected from unnecessary mechanical damage |
| 6. Test the system | Have the completed installation checked before energising the system |
Important: Solar DC wiring can carry dangerous voltage and current. Installation should be carried out by a qualified solar/electrical technician.
| Item | Quantity |
| PV1-F Solar Cable | As Ordered |
| Copper Conductor | Built-In |
| XLPO Insulation | Built-In |
| Colour | Black or Red |
| PV Connectors | Not Included Unless Specified |
| Solar Panels | Not Included |
| Inverter | Not Included |
| Prime Nexu Advantage | What You Get |
| Ghana-Focused Supply | Solar wiring selected for local installation needs |
| Multiple Sizes | Choose from 1.5mm² to 10mm² options |
| Easy Ordering | Order directly through WhatsApp |
| Solar Installation Products | Source cables, panels, batteries, inverters and other solar equipment |
| Project Orders | Ask us about larger quantities |
| Nationwide Delivery | Delivery available across Ghana |
| Location | Delivery Time |
| Accra | 1–2 Working Days |
| Kumasi | 1–3 Working Days |
| Takoradi | 1–3 Working Days |
| Tamale | 2–5 Working Days |
| Other Regions | 2–5 Working Days Nationwide |
Delivery time may vary depending on product availability, order size and destination.
